Compact Electronic General Purpose Timeswitch with Voltage Free Contacts, 24 Hour/7 Day, 16A, White
Compact Electronic General Purpose Timeswitch with Voltage Free Contacts, 24 Hour/7 Day, 16A, White
Part Code:
NTT04
Stock Availability
Product Details
Part Code:
NTT04
- 16(4)A load rating
- 4 ON/4 OFF easy-set programme periods per day, 28 ON/28 OFF programmes per week
- Shortest switching time 1 minute
- Extra large 'Easy View' screen with blue LED backlighting
- Red LED 'Mains ON' and green LED 'Output' indicators for easy viewing
- Switches up to 750W incandescent or halogen lighting/750W fluorescent lighting/100W compact fluorescent lighting (cfl’s)/100W LED lighting (Not suitable for discharge lighting)
- Large easy push programme buttons
- Self-cancelling override button to next programme change
- Optional 1 and 2 hour boost button
- Automatic Summer/Winter changeover
Downloads
Specifications
| Depth | 59mm |
| Display Type | Digital Display |
| Height | 92mm |
| Manufacturer Part Code | NTT04 |
| Programmer Type | 24 hour, 7 Day |
| Width | 92mm |
